Thermostats- HA308S1-TL Digital floor sensing thermostat 16amp manual or programmable

The PAPHA308S1-TL is a digital floor sensing thermostat that is designed to provide precise temperature control for your space. With a maximum 16amp load capacity, this thermostat is suitable for both non-programmable and programmable applications.

Its floor sensing feature ensures accurate temperature readings and allows for optimal comfort.

The digital display provides clear and easy-to-read information, making it convenient to adjust the temperature settings.

Whether you prefer a fixed temperature or the flexibility of programmable options, this thermostat offers the versatility to meet your needs. With its reliable performance and user-friendly interface, the HA308S1-TL is an excellent choice for anyone seeking efficient and convenient temperature control.

Technical data

Size: W110x H110 x D40mm (30mm in wall)

Protection Rating: IP21

Max Load: 16A

Colour: White

Orientation: Landscape or Portrait

Temperature Range: 5 ~ 40°C (0.5°C increments)

Sensor rating: NTC 12kΩ @ 25°C

1x thermostat1x floor sensor1x instructions

Wall mounted - square with 60mm mounting holes requires a wall box mounting or a c clip adjust to match mounting holes
